12SL40210
SWITCH 12SL40210 | 系列号：SL
SL series is a sealed heavy duty interlock switch perfect for outdoors and harsh environment applications. It is offered with 0.187"quick connect terminal or potted 12 inches (304.8 mm) wire long and IP67 rated.
| 参数 | 数值 |
|---|---|
电路 | SPDT NO / NC |
Rating - Minimum Current | 5 mA |
Terminals Type | 快速连接 |
Terminals Complementary Information | 0.187 |
Terminals Plating | Without plating |
Contact Plating | 银合金 |
Electrical Rating - Activated - Voltage DC | Min 30 Volt / Max 30 Volt |
Electrical Rating - Activated - Voltage AC | Min 125 Volt / Max 250 Volt |
高度 | 45.97 |
触点 | 快速连接 |
- IP60/IP67 rated
- From 0.1A to 10A max.
- AC or DC rating voltage
- Push (MOM)/pull motion (maintained)
- Threaded or non-threaded plunger
- SPDT or DPDT (extended SS bracket)
- Integrated wire harness solution
12SL40210 应用
- Industrial food equipment
- String converters
- Test lab equipment
- Panel Builders
- Industrial enclosures
